Flowmeter, GPM/LPM 10-100/50-380

Item Mechanical Flowmeter Housing Material Aluminum Type Variable Area For Pipe Size 1 1/4 in Connection Size 1 1/4 in Flow Material Petroleum Fluids Connection Type NPTF Max. Pressure 3,500 psi Max. Viscosity 500 SUS Wetted Materials Aluminum Flow Range 10 to 100 gpm Fluid Temp. Range -20 Degrees to 240 Degrees F Height 4 11/16 in Flow Range @ GPM/LPM 10 to 100 / 50 to 380 Height (In.) 4-11/16 Max. Temp. (F) 240 Standards ANSI B2.2 Accuracy (%) +/-2% Full Scale Seal Material Viton Pressure Drop - 100% Flow (PSI) 15.0 psi Specific Gravity 0.876 Width 4 3/8 in Pressure Drop - 50% Flow (PSI) 6.5 psi Chamber Material Aluminum Length (In.) 12-3/16" Shaft Material Not Applicable Width (In.) 4-3/8" Connection Size (In.) 1-1/4 FNPT Length 12 3/16 in Max. Pressure (PSI) 3500 Display Type Scale Output Type Not Applicable Product Type Petroleum Fluid Meter Operating Pressure - Maximum 3,500 psi Accuracy +/-2% Includes Flow Rate Adjustment Knob No Overall Length 12.2 in Media Temperature - Minimum -20 Degrees F Compatible Flow Material Petroleum Fluids Flow Rate - Minimum 10 gpm O-Ring Material Viton Media Temperature - Maximum 240 Degrees F Overall Width 4.1 in Unit Of Measure Gallons, Liters Wetted Material Aluminum Pulse Rate Not Applicable Includes Totalizer No Viscosity - Maximum 500 SUS Cable Length Not Applicable Flowmeter Type Variable Area Frequency - Minimum Not Applicable Mounting Orientation Universal Flow Rate - Maximum 100 gpm Frequency - Maximum Not Applicable Overall Height 4.7 in Includes Pressure Gauge No Voltage - Maximum Not Applicable Rotor Material Not Applicable Country of Origin (subject to change) United States Package Quantity 1
